Flat Teeth Bucket Teeth for Drilling Bauer FZ Series

Application: Suitable for drilling in sandy stone of foundation piles.

Material: Tungsten carbide: YG11C, HRC88-92 + 35MnB.

Models: BFZ162, BFZ70, FZH70, BFZ72, FZH72, BFZ79, FZH79, BFZ80, FZH80.

Features
  1. The carbide tip use the low-cobalt material, with bigger carbide tip, with stronger abrasion resistance;
  2. Advanced processing, to guarantee the carbide tips high quality.
  3. The carbide tip has well-distributed micro-particles, with super impact strength, it will make higher force intensity during the drilling, and reduce the risk of breaking or cracking the teeth.
Parameters
Part No. Description Unit Weight (Kg)
BFZ162/100/70 Flat Teeth 2.75
FZH70 Holder 1.1
BFZ72 Flat Teeth 2.75
FZH72 Holder 1.1
BFZ79 Flat Teeth 2.9
FZH79 Holder 2.1
BFZ80 Flat Teeth 3.0
FZH80 Holder 2.3
Advantages
  1. The body surface is smooth, less resistance, fast drilling efficiency.
  2. The carbide teeth has multi-step, low probability of partial friction.
  3. Big carbide size, smart and drilling faster.
